Breakthrough in dye development for fluorescence-guided cancer surgery

Fluorescence imaging with short-wave infrared has the potential to increase the precision and safety of cancer surgery considerably. However, until now, there have been very few dyes that can be used in clinical settings. An international team of researchers led by scientists at the National Cancer Institute (Bethesda, Maryland, USA) and Helmholtz Zentrum München has now developed two new fluorescent dyes for short-wave infrared and a corresponding imaging system. For the first time, this opens up the possibility of making certain structures – such as the tumor, the surrounding healthy tissue and draining lymphatic vessels – visible simultaneously in a smooth video during surgery. Following his appointment to the National Center for Tumor Diseases Dresden (NCT/UCC), Professor Oliver Bruns will continue to develop this innovative imaging method for cancer surgery in Dresden. The results have been published in the prestigious Nature Methods journal (https://doi.org/10.1038/s41592-022-01394-6).

The National Center for Tumor Diseases Dresden (NCT/UCC) is a joint institution of the German Cancer Research Center (DKFZ), University Hospital Carl Gustav Carus Dresden, the Faculty of Medicine Carl Gustav Carus of TU Dresden and the Helmholtz-Zentrum Dresden-Rossendorf (HZDR).

Tumor surgery is a precision job. The aim is to remove the tumor and any metastases, while protecting healthy tissue and surrounding risk structures, such as nerves and vessels, as far as possible. It is hoped that, in future, fluorescence imaging using short-wave infrared (SWIR) with wavelengths greater than 1,000 nanometers will support surgeons in this difficult task. SWIR can produce much sharper images and provide insights into deeper tissue layers than is possible with conventional fluorescence imaging using infrared wavelengths between 700 and 900 nanometers. In addition, the innovative method offers the potential to light up selected tissues, vessels and body fluids simultaneously. Now that prices for suitable cameras have fallen considerably, thanks to rapid developments in industry, suitable dyes are the key bottleneck for medical application. “The advances achieved here in dye and technology development are now, for the first time, creating the necessary conditions for the visualization of various structures, such as tumors, draining lymphatic vessels and sentinel lymph nodes, in a process as dynamic as fluorescence-guided surgery,” says Professor Oliver Bruns, who was appointed Professor of Functional Imaging in Surgical Oncology at the National Center for Tumor Diseases Dresden (NCT/UCC) in February in a joint process involving TU Dresden and the German Cancer Research Center (DKFZ), and who is also a research group leader at Helmholtz Zentrum München. The results achieved in the field of fluorescence imaging during his time at Helmholtz Zentrum München form an important basis for future research in Dresden.

To develop the dyes, the researchers focused on cyanine dyes, which are some of the most frequently employed dyes in multicolor fluorescence microscopy. However, only a few of them are suitable for imaging in living organisms and in the SWIR range. Fluorescence dyes are generally administered intravenously and can sometimes be conjugated with antibodies that can be used to bind the dyes specifically to tumors. Through targeted computer-assisted further development of a clinically approved class of molecules, the researchers succeeded in developing two new dyes (FNIR-872 and FNIR-1072) that emit most of the light in the SWIR range following optical excitation. “Other key properties of the newly developed dyes are that they are non-toxic, highly water-soluble and can be conjugated with biomolecules that transport the dyes to the target structures in the organism,” explains Dr. Martin Schnermann of the National Cancer Institute.

Alongside their work on the dyes, the researchers also developed an imaging system with three lasers and an LED light source. This makes it possible to use indocyanine green (ICG), a dye that is already approved and which is suitable for SWIR imaging, at the same time as the two newly developed dyes, with their respective wavelengths. The different types of image information can be merged into one image and converted into a smooth video at a rate of eight frames per second. This opens up the possibility of giving surgeons a continuous view of all important target and risk structures during an operation. By contrast, conventional fluorescence imaging can only highlight individual structures, and the image quality is poor. The new imaging system also has the advantage of not being sensitive to visible light, so operations can be carried out under normal surgery theater lighting.

The new dyes and imaging system have already been successfully tested in preclinical experiments. In future, the aim is to further optimize the properties of the dyes so that they can, for instance, be produced more easily and conjugated more effectively with various biomolecules. “Our aim is for the new dyes and imaging system to be clinically available in a few years,” says Professor Bruns.

Publication:
Bandi, V.G., Luciano, M.P., Saccomano, M. et al. Targeted multicolor in vivo imaging over 1,000 nm enabled by nonamethine cyanines. Nat Methods (2022). https://doi.org/10.1038/s41592-022-01394-6
Fulltext: https://rdcu.be/cHVTz

A print-quality photo is available to accompany the press release:
https://www.nct-dresden.de/fileadmin/media/nct-dresden/das-nct/newsroom/pressemitteilungen/Fluoreszenz-Bildgebung1.png
CAPTION 1: Innovative fluorescence imaging reveals the tumor (blue), lymphatic vessels (green) and blood vessels (magenta). © Dr. Mara Saccomano, Helmholtz Munich
